Sigen Energy Controller 8.0 kW Single Phase
Sigen Energy Controller 8.0 kW Single Phase
- EMS inside for precise control
- on & off-grid compatibility
- DC ground-fault protection
- DC/AC ratio up to 2 (single phase)
- Multi-source black start
- IP66 protection rating
Availability:In stock
SKU SIG-EC8.0-SP
Sigen Energy Controller 8.0 kW Single Phase
The Sigen Energy Controller 8.0 kW Single Phase is a high-capacity hybrid inverter designed for large residential and light commercial applications. It delivers powerful energy management, ensuring efficient utilization of solar generation and battery storage.
Fully integrated within the SigenStor platform, it supports advanced monitoring, seamless system control, and reliable backup power for demanding energy environments.
Key Features
- Rated Power: 8.0 kW
- Phase Type: Single Phase
- High-capacity hybrid inverter
- Ideal for large energy consumption systems
- Real-time monitoring and smart control
- Backup power functionality
Resources
Installation Guide Alarm List Important Notice
| Color | White |
|---|
| Storage temperature range | -40 ~ 70°C |
|---|---|
| Relative humidity range | 0% ~ 95% |
| Max. operation altitude | 4000 m |
| Communication | WLAN / Fast Ethernet /RS485 / Sigen CommMod (4G/3G/2G) |
| Standard | IEC/EN 62109-1, IEC/EN 62109-2, IEC/EN 62477, IEC/EN 61000-6-1, IEC/EN 61000-6-2 |
| Max. DC Input Voltage (V) | 600 |
|---|---|
| Nominal DC input voltage | 350 V |
| Start-up Voltage | 100 V |
| MPPT voltage range | 50 ~ 500 V |
| No. of MPP Trackers | 3 |
| Number of PV strings per MPPT | 1 |
| Operating temperature range | -30°C ~ 60°C |
| Max. input current per MPPT | 16 A |
| Max. short-circuit current per MPPT | 20 A |
| Max. Efficiency | 97.6% |
| Dimension (w/h/d) mm | 700/300/260 |
|---|---|
| Weight (kg) | 36 |
| Color | White |
|---|
| Storage temperature range | -40 ~ 70°C |
|---|---|
| Relative humidity range | 0% ~ 95% |
| Max. operation altitude | 4000 m |
| Communication | WLAN / Fast Ethernet /RS485 / Sigen CommMod (4G/3G/2G) |
| Standard | IEC/EN 62109-1, IEC/EN 62109-2, IEC/EN 62477, IEC/EN 61000-6-1, IEC/EN 61000-6-2 |
| Max. DC Input Voltage (V) | 600 |
|---|---|
| Nominal DC input voltage | 350 V |
| Start-up Voltage | 100 V |
| MPPT voltage range | 50 ~ 500 V |
| No. of MPP Trackers | 3 |
| Number of PV strings per MPPT | 1 |
| Operating temperature range | -30°C ~ 60°C |
| Max. input current per MPPT | 16 A |
| Max. short-circuit current per MPPT | 20 A |
| Max. Efficiency | 97.6% |
| Dimension (w/h/d) mm | 700/300/260 |
|---|---|
| Weight (kg) | 36 |
