Sigen Energy Gateway C&I 60 kW
Sigen Energy Gateway C&I 60 kW
Sigen Gateway C60 AU (for Australia)
- 60 kW three-phase energy gateway for C&I systems
- Seamless backup transition with 0 ms interruption
- Advanced energy management and real-time monitoring
- Supports connection with SigenStor battery systems
- Compatible with diesel generators (2-wire auto-start)
- Built-in bypass circuit for maintenance and reliability
- Anti-backflow protection (export limitation)
- Remote monitoring and control via mySigen App
- Scalable for micro-grid and large energy systems
Availability:In stock
SKU SIG-GW-C60-TP
Sigen Energy Gateway C&I 60 kW
The Sigen Energy Gateway C&I 60 kW is an intelligent energy management and backup control unit designed for commercial and industrial (C&I) applications. It serves as the central interface between the grid, photovoltaic (PV) system, energy storage (SigenStor), and electrical loads, ensuring seamless energy flow and uninterrupted power supply.
With a 0 ms transfer time, the gateway provides instant switchover to backup power during grid outages, guaranteeing continuous operation of critical loads.
System Integration
- Supports multiple SigenStor connections for scalable systems
- Interfaces: RS485, Ethernet, dry contact I/O
- Compatible with energy management systems (EMS)
- Supports generator integration for extended backup
Applications
- Commercial buildings and facilities
- Industrial plants and factories
- Micro-grid and hybrid energy systems
- Solar + battery + generator backup solutions
- EV charging hubs and critical load systems
Key Benefits
- Ensures uninterrupted power supply during outages
- Optimizes energy usage and reduces operational costs
- Enables zero-export compliance and grid protection
- Flexible and scalable for future system expansion
- Fast installation and commissioning
| Storage temperature range | -40 ~ 70°C |
|---|---|
| Operating temperature range | -30 ~ 55°C |
| Relative humidity range | 0% ~ 100% |
| Max. operation altitude | 4,000m |
| Communication | Fast Ethernet, RS485, dry contact |
| Dimension (w/h/d) mm | 510 / 795 / 173 |
|---|---|
| Weight (kg) | 35 |
| Storage temperature range | -40 ~ 70°C |
|---|---|
| Operating temperature range | -30 ~ 55°C |
| Relative humidity range | 0% ~ 100% |
| Max. operation altitude | 4,000m |
| Communication | Fast Ethernet, RS485, dry contact |
| Dimension (w/h/d) mm | 510 / 795 / 173 |
|---|---|
| Weight (kg) | 35 |
