Sigen EV DC Charging Module 25kW 10m Cable CCS2
Sigen EV DC Charging Module 25kW 10m Cable CCS2
Sigen EV DC Charging Module
- V2H power supply, ample backup energy
- V2G power transfer, ready for energy trading
- EV-supported home energy system black start
- Max. 25kW stable bi-directional charging
- 150V ~ 1000V charging, wide EV compatibility
- Charge EV with 100% solar power
- Track & schedule charging on mySigen App
- IP66 system protection, maintenance free
- 10m Cable CCS2
Availability:In stock
SKU SIG-EVDC25-5S2
BrandSigenergy
Sigen EV DC Charging Module
A truly future-ready solution, the Sigen EV DC Charging Module delivers up to 25 kW of bi-directional charging, serving as a vital link between electric vehicles and residential energy systems. Built on an advanced DC-coupled architecture, it enables direct charging of EVs using solar-generated clean energy—supporting a more sustainable and environmentally friendly way to power mobility.
EV–Home Energy Integration
The Sigen EV DC Charging Module transforms your EV into more than just transportation. It helps keep your home running during power outages, offers opportunities to earn by feeding energy back to the grid, and allows you to charge your vehicle using solar power.
Vehicle-to-Home (V2H):
Enhance your home’s backup power by using your EV as an energy source. When paired with the Sigen Battery, the system can provide over 100 kWh of storage capacity for extended energy security.
Advanced Vehicle-to-Grid (V2G) Capability
Designed to work with power grids in most countries, this innovative system brings V2G technology to the next level. Imagine millions of EVs functioning as a unified energy storage network—supporting grid stability, reducing peak demand, and maximizing battery value over time. This approach not only benefits EV owners financially but also contributes to global carbon neutrality efforts.
Vehicle-to-Grid (V2G):
Enables EV batteries to return energy to the grid, helping with peak shaving and efficient load balancing.
DC Charging
| Max. charging power of charging port (kW) | 25 |
|---|---|
| Max. discharging power of charging port (kW) | 25 |
| Operating Voltage (Vmp) | 150 ~ 1000 |
| Operating Current (Imp) | 80A |
| Charging interface | CCS2 |
Protection
| Short-circuit protection | Supported |
|---|---|
| Over / Under voltage protection | Supported |
| Overload protection | Supported |
| Over temperature protection | Supported |
| Reverse polarity protection | Supported |
| Welded contactor check | Supported |
General Data
| Dimension (w/h/d) mm | 700x270x260 |
|---|---|
| Weight (kg) | 41.00 |
| Cooling | Smart air cooling |
| Ingress protection rating | IP66 |
