Sigen Power Sensor Single Phase External CT 100 A DH
Sigen Power Sensor Single Phase External CT 100 A DH
- 1% high-accuracy power detection for precise control
- LCD real-time info display, easy to operate and check
- Integrates smoothly with Sigenergy devices, no need for setup
- Top class 100 A direct connection in power sensor with built-in CT
- Support export/import limitations and ready for AI evolving
- 100 ms data refresh rate, instantaneous data feed
Availability:In stock
SKU SIG-SEN-SP-CT100-DH
BrandSigenergy
Sigen Power Sensor Single Phase External CT 100A DH
The Sigen Power Sensor Single Phase External CT 100A DH is a compact and efficient energy monitoring device designed for single-phase electrical systems. It enables accurate measurement of power consumption by using an external current transformer (CT), allowing users to gain clear insight into their energy usage.
Designed for seamless integration with Sigenergy energy solutions, the sensor supports real-time monitoring and intelligent energy management. It helps optimize energy consumption, control power flow, and improve overall system efficiency in residential or small commercial installations.
With its plug-and-play design, the device can be easily installed on a DIN rail without requiring complex configuration. Its compact form factor and user-friendly setup make it ideal for quick deployment in modern energy systems.
The sensor provides high-accuracy data and fast response, enabling features such as import/export control and advanced energy optimization. It works closely with Sigenergy controllers and battery systems to support smarter, more efficient energy usage.
Technical Specifications
| Grid connection type | 1P2W |
|---|---|
| Nominal AC frequency | 50 / 60 |
| Rated input voltage | 176 ~ 276 Vac |
| Voltage accuracy | 0.5% |
| Current accuracy | 0.5% |
| Power accuracy | 1% |
| Frequency accuracy | 0.2% |
Communication
| Interface | RS485 |
|---|---|
| Baud rate | 9600bps |
| Protocol | Modbus RTU |
General Data
| Dimension (w/h/d) mm | 19 / 94 / 68 |
|---|---|
| Weight (kg) | 0.07 |
| Operating temperature range | -40°C ~ +70°C |
| Storage temperature range | -25°C to +65°C |
| Relative humidity range | 0% to 90% |
| Ingress protection rating | IP20 |
Standard Compliance
| Standard | EN 61010-1:2010, EN 61010-2-030:2010 |
|---|
